Industrial Solid-state Laser Pump Module


Category

Industrial solid-state laser pump module


The 8XXnm fiber coupling module is widely used in solid-state lasers and medical aesthetics. The 8XXnm pump module launched by Dogain has the characteristics of high wall-plug conversion efficiency, full current wave-locking, wide temperature wave-locking range, and precise spectral control. The output power of the product covers 0~500W, which can meet the requirements of the current solid-state laser for pump power and wavelength.



Features

  • Full current lock wave
  • High reliability and brightness
  • Single emitter module
  • Compacted size

Applications

Industrial Processing

Scientific Research

Laser Display

Laser Medical

Prev

Next

Prev

Next

Model

DG-Z6-65-878.6-400-VBG

DG-Z12-100-940-105

DG-Z14-270-915-135

DG-Z16-13X-350-976-220

DG-Z16-350-976-200

DG-Z16-380-915-200

DG-Z16-450-976-220

DG-Z18-300-808-200-Q

DG-Z18-500-915-220

DG-Z18-500-976-220

DG-Z19-350-976-135

DG-Z20-200-976-105

Wavelength

878.6

940

915

976

976

915

976

808

915

976

976

876

Power

65

100

270

350

350

380

450

300

500

500

350

200

Fiber Core (μm)

400

105

135

220

200

200

220

200

220

220

135

105
